Para Laboran, Analis Laboratorium lebih-lebih Manager atau Kepala Laboratorium pastinya mengenal UV/Vis Spectro photo meter, namun ini akan kami tampilkan barangkali bisa untuk mereiview dan atau ada yang sedang mencari UV/Vis Spectrophotometer Single Beam silahkan di baca, akan tetapi artikel ini saya sajikandalam bahasa Inggris, bagiyang membutuhakn keterangan silahkan hubungi email kami membagiilmuoehsunarta@gmail.com atau sun_elarta@yahoo.com atau apabila inign WA ke nomor 082137320434 berikut artikelnya :
FEATURES :
·
Data output
: Data can be exported to U disk ( USB output )
·
Pre-aligened design ensures the user can be
change lamps conveniently.
·
With SiO2 Coating optical mirror , reducing
the pollution from outsid fully.
·
Ptint Port : Instrument can connect PCL
printer to printing A4 paper ( USB port )
·
Imported & Environmental Deuterium lamp,
preventing from Ozone inhalation
·
Real –Time Monitoring the Life time of
Deuterium lamp and Tungsten Lamp with advance d system
·
Large LCD screen ( 480*272 )with 65 thousand
true color and support U disk data saving
·
Wavelength calibration , wavelength setting ,
Change lamp source and dark current calibration automatically.
·
Adopted high Class grating with wholly
hermetic light path design, to insure the instrument has the super stray light.
·
With GLP self check function, check the wave
length accuracy and Phtometry accuracy, can provide test report and power off
protection.
BASIC FUNTION :
·
Photometry :
Test Abs, Transmittance and Energy by Fixed wavelength.
·
Quantitaive :
Liniar fit and Linear fit through Zero
two models
a. Coefficient,
Standard sample input and standard sample read three modes to establish
standard curve
b. Establish
A=K1*C+K0, can search original data
graph curve , parameter setting.
c. Can
save 240 groups curve . can test 240 data in each curve
d. Double
wavelength , triple wavelength test function.
·
Kinetics :
Used for time course scanning or
reaction rate calculation ΔA/t, can search All data.
·
Multi Wavelength :
Can test Transmittance and Abs with 8
different wavelength at most
·
Scanning:
User can set the scan range from 190 nm
to 1100 nm to test the max. Abs.peak value can do derivation, arithmetical
operations to the graph.
·
Biology
6 Methods : DNA / protein, UV,
Lowry,BCA,CBB,and Biuret.
TECHNICAL PARAMETERS :
Optical System : Single Beam , Grating 1200
lines/mm
Wavelength range : 190 ~1100 nm
Spectral Bandwidth : 2 nm
Wavelength Accuracy :
± 0.5 nm
Wavelength Repeatability :
≤ 0.2 nm
Photometric Accuracy :
± 0.002A ( 0~0.5 Abs), ±0.004A ( 0.5 ~ 1.0 Abs ),±0.5% T(0~100%T )
Photometric Repeatability :
0.001Abs(0~0.5Abs), 0.002 Abs(0.5 ~1.0 Abs),≤ 0.2% T(0 ~100 % T )
Stray Light :
≤ 0.04 % T@360nm , 220 nm
Stability :
± 0.001A/h @ 500 nm
Baseline Flatness : ± 0.002A
Noise :
0.0005Abs @500 nm
Display :
480*272 65 thousand true color TFTLCD
Photometric mode :
T , A , C , E
Photometric range :
0 ~ 200 % T, - 0.301 ~ 3.0 A
Detector :
Silicone Photodiode
Light source :
Deuterium Lamp , Tungsten Lamp
Input :
Membrane Keypad
Output :
USB Print and dataoutput, Conect PC
Standard Accerories :
10 mm glass Cuvette 4 units
10 mm quartz cuvette 2 units
Power Suplay :
110/220 V ± 10%, 60/50 Hz
Packing Size ( W*D*H)mm: 620*500*370
Gross Weight :
18 Kg
